SW-1000AP A Scan and Pachymeter

$0.00

Model: SW-1000AP

Applications:

Quantity:

Purchase diagnostic ultrasound equipment for clinic, hospital, or become our distributor. Send an inquiry or contact us now.

Send Inquiry

Chat on WhatsApp: +8613618377608

SW-1000AP A Scan and Pachymeter

Features:

A Scan

  • Large color liquid-crystal screen
  • Touch screen input, easy operation
  • Curve freezing: Manual/Auto mode, controlled by pedal
  • Built-in speed thermal printer
  • Enter the name & ID; easy to check archive

P Scan:

  • Large color liquid-crystal screen
  • Touch screen input, easy operation
  • Curve freezing: Manual/Auto mode, controlled by pedal
  • Built-in speed thermal printer
  • Can display ultrasound waveform when measuring
  • Each group is the average of 20 measurements
  • Switch between IOP measured value and actual value

Technical Specifications:

A scan probe

10MHz import small size probe, built-in luminotron

Measuring range

15mm-40mm

Measurement precision

±0. 05mm; with macula lutea trace function

Measurement

Anterior chamber depth, lens thickness, vitreous body length, total length and average

Method of measurement

immersion and contact

Eye mode

Phakic/ Aphakic/Dense/ various IOL

IOL formula

SRK-II, SRK-T, BINKHORST- Ⅱ, HOLLADAY, HOFFER-Q, HAIGIS

Storage

10 cases, 5 readings each case

Output

A scan waveform and IOL calculation sheet



P scan probe

20MHZ, angle of 45 degrees makes easier operation

Resolution:

5um

Measuring range

150um~1500um

Display

SINGLE mode and MAP mode

Chongqing Vision Star S&T Co., Ltd. is a leading supplier of ultrasound machines, offering a wide range of products for both human and veterinary use. Our product line includes color doppler ultrasound machines, black and white ultrasound machines, and more.

Our ultrasound machines are designed to provide high-quality imaging for accurate diagnosis and treatment planning. The color doppler ultrasound machines offer detailed and real-time imaging of blood flow, making them ideal for cardiovascular and obstetric applications. On the other hand, the black and white ultrasound machines provide clear and precise images for a wide range of medical examinations.

With a commitment to innovation and quality, Chongqing Vision Star S&T Co., Ltd. ensures that our ultrasound machines meet the highest standards in the industry. Whether it is for human healthcare or veterinary medicine, our products are trusted by professionals worldwide for their reliability and performance.

Choose Chongqing Vision Star S&T Co., Ltd. for advanced ultrasound technology that delivers accurate and efficient results in medical imaging.
