SW-2100 AB Scan
$0.00
SW-2100 AB Scan
Features:
With Normal, Vitreous body enhancement, retina observation model, SW-2100 is mainly used for diagnosis of introcular diseases, display the location, shaper range of the focus of infection and relationship with the surrounding tissue. Can be diagnosed vitreous opacity, retinal detachment, eye base tumors, etc. eye diseases. A scan is used to measure chamber depth, lens thickness, axial length, calculate diopter of implant IOL as well.
Specifications:
| A Scan | B Scan | ||
| Frequency | 10MHz, with LED | Frequency | 10MHz/20MHz (optional) ,Magnetic driven, noiseless |
| Depth | 40mm | Scanning Mode | Sector Scanning |
| Precision | ±0.05 mm | Magnify | Multi continuous magnification,Real-Time magnification |
| Measurement | Anterior chamber depth, lens thickness, | Resolution | Lateral ≤0.3mm; Vertical≤0.2mm |
| vitreous body length, total length and average | Geometry position precision | Lateral ≤10%; Vertical≤5% | |
| Depth | 60mm | ||
| Gain of probe | 30dB-105dB | ||
| Eye mode | Phakic / Aphakic / Dense / Various IOL | Scanning Angle | 53° |
| IOL Formula | SRK-II, SRK-T, HOFFER-Q, HOLLADAY,BINKHORST-II, HAIGIS | Gray Scale | 256 |
| False Color | Multi colors. OCT | ||
| measurement type | Multigroup distances, perimeters and areas | ||
| Stat. Calculation | Average and standard deviation | Movies | 100 images movie review, AVI JPG format image output |
| Store | 10 Scanning results for each eye | Image postprocessing | multiple curves processing, Pseudo-color processing curve |
| Display Mode | B, B B, B A, A | ||
| Hint | Preset keyword | ||
| Case Search | Multi-keywords | ||
| Working Platform | Windows XP, VISTA, WINDOWS7 | ||
| User-defined report template | with | ||
Chongqing Vision Star S&T Co., Ltd. is a leading supplier of ultrasound machines, offering a wide range of products for both human and veterinary use. Our product line includes color doppler ultrasound machines, black and white ultrasound machines, and more.
Our ultrasound machines are designed to provide high-quality imaging for accurate diagnosis and treatment planning. The color doppler ultrasound machines offer detailed and real-time imaging of blood flow, making them ideal for cardiovascular and obstetric applications. On the other hand, the black and white ultrasound machines provide clear and precise images for a wide range of medical examinations.
With a commitment to innovation and quality, Chongqing Vision Star S&T Co., Ltd. ensures that our ultrasound machines meet the highest standards in the industry. Whether it is for human healthcare or veterinary medicine, our products are trusted by professionals worldwide for their reliability and performance.
Choose Chongqing Vision Star S&T Co., Ltd. for advanced ultrasound technology that delivers accurate and efficient results in medical imaging.
