UCD3T Trolley Color Doppler Ultrasound Scanner

Description

UCD3T Trolley Color Doppler Ultrasound Scanner

Feature:

1.4D real skin rendering function.
2.Advanced YH+ Operation Platform.
3.Matching high-speed 4G+128G Intel PC platform.
4.Improving data processing capabilities.
5.Getting Better man-machine interraction and inspection fluency Sub-array Technology.
6.Fully displaying the high-resolution images Perfectly presenting image details.
7.Greatly increase the accuracy of clinical diagnosis .
8.Sharing function: sharing Video and pictures on the PC side in real time via LAN.
9.DICOM 3.0: connecting with the PACS of hospital, quick Transmission.
10.One-key optimized function; obtaining better images in a flash; saving operating time.

Application:

Abdomen, Pediatrics, Cardiology, Gynecology, Small parts, Urology, Obstetrics, Vascular, MSK. Measurement package of abdomen, obstetrics, urology, etc. for giving clinicians more scientific diagnosis assistant.

Main specifications and system overview:
1.Operating system: Windows 10
2.Pulse Wave Doppler
3.Directional Energy Doppler
4.Real-time triple synchronization
5.Spatial Composite Imaging
6.Tissue Harmonic Imaging
7.2B/4B Imaging
8.Support system languages: Chinese, English, French, Russian, Spanish.
9.Standard monitor size: 21.5 inch, high-definition medical grade LCD display, and 13.3 inch touch-screen.
10.Integrated clipboard: display the saved images at the bottom of the screen, which can be directly transferred or deleted
11.With on-site upgradeable functions
12.Preset conditions: For different inspections, preset inspection conditions for optimized images, reducing adjustments during operation, and commonly required external adjustments and combined adjustments
13.Probe ports: 4 active
14.Trapezoidal Imaging
15.One-key auto optimization

Optional Probes:
1.Convex probe: 2.0MHz/2.5MHz/3.0MHz/3.5MHz/4.0MHz/5.5MHz/H4.0MHz/H5.0MHz,(depth 30-255mm)

2.Linear probe: 6.0MHz/7.5MHz/8.5MHz/8.0MHz/12.0MHz/H8.0MHz,(depth 20-128mm)

3.Trans-vaginal probe: 4.5MHz/5.0MHz/6.0MHz/6.5MHz/7.0MHz/9.0MHz/H8.0MHz, (depth 30-156mm)

4.Phased array probe: 2.0MHz/2.5MHz/3.0MHz/3.5MHz/4.0MHz/5.0MHz/H3.0MHz/H4.0MHz,(depth 80-244mm)

5.Micro convex probe (R15): 4.0MHz/6.0MHz/7.0MHz/8.0MHz/H8.0Mhz,(depth 30-91mm)

6.Micro convex probe(R20):4.5MHz/6.0MHz/7.0MHz/9.0MHz/H8.0Mhz,(depth 30-91MM)

7.Rectal probe:4.0MHz/6.5MHz/9.0MHz/H8.0Mhz,(depth 20-91MM)
