UCD8T 4D Echo Color Doppler Trolley Ultrasound Machine

UCD8T 4D Echo Color Doppler Trolley Ultrasound Machine

The high-end ultrasound applies outstanding image resolution, intelligence operation flow, ergonomic design and intimate man-machine interaction as an organic whole. High quality clinical performance, rich measurement software can quickly and conveniently solve the needs of cardiology, abdominal, peripheral vascular, superficial parts, skeletal muscle, gynecology, obstetrics, urology, newborn and other clinical diagnosis. Stable platform and user-friendly operation design improve the work efficiency of doctors to a greater extent.

Video:

Feature：

1.21.5 inch LED medicinal monitor + 13.3 inch touch screen
2.Lifting and rotating platform with adjustable height and movable rotation function
3.PDI, PW, CW, 2D, 3D, 4D , TDI, Auto IMT/NT
4.Puncture enhancement, Panoramic, Trapezoid Imaging,
Color M, Anatomical M mode
5.PC Windows system
6.Rich measurement packages
7.USB ports,HDMI,DICOM 3.0
8.Trapezoidal Imaging
9.B/SRI:real-time dual image display
10.Panoramic imaging

Main specifications and system:
1.Applications：Abdomen, obstetrics, gynecology, heart, urinary system, small organs, superficial, blood vessels, pediatrics, newborns, musculoskeletal
2.Probes：Convex probe, Tran-vaginal probe, Linear probe, Micro-convex probe, Cardiac probe,4D Volume
3.Real time 3D imaging（3D/4D）
4.Applications and report：Abdominal,OB,GYN,Cardiac,Urinary,Small Parts,Superficial, Vascular, Pediatrics, Advanced measurement software packages, report software packages, case management software packages, etc.
5.carotid artery intima measurement thickness(IMT）
6.Automatic spectral envelope measurement
7.Full digital transmission and reception of beam synthesizer
8.Color Doppler imaging（C）
9.Pulse Doppler Imaging（PW）
10.Coherent Contrast imaging（CCI）
11.Continuous wave Doppler imaging（CW）
12.B/C/D Real-time three synchronous imaging
13.Power Doppler imaging（PDI）
14.Direct power Doppler imaging（DPDI）
15.M mode imaging
16.Anatomic M mode imaging
17.Color Doppler M mode imaging
18.Elastography
19.Tissue Doppler imaging（TDI）
20.Strain rate imaging (SRI)
21.Tissue harmonic imaging（THI）
22.Fusion harmonic imaging（FHI）
23.Speckle Reduce imaging（SRI）
24.Panoramic imaging
25.Deflection imaging
26.Trapezoidal imaging
27.Adaptive velocity optimization
28.Free hand 3D

Measurement and analysis function:
1.General measurement: Distance, area, ellipse, cross line, angle, distance ratio, volume, Volume (ellipse), area ratio, diameter, joint angle
2.Cardiac：Automatic spectrum envelope、LV、Main Pulmonary artery diameter、RVEDd、LVM、LAV、HR、MVF、AO、AR、LVOT、TVF、Pulmonic valve、Pulmonary vein、RV、Doppler fetal heart sound、LVET、LVM、LVMI、AV
3.Vascular: carotid intima (IMT), length stenosis ratio, area stenosis ratio, IMT (back wall), IMT (front wall)
4.OB：Fetal routine、AFI、TW、GS、CRl、OFD、HL、ulna、NT、Fibula、Nbonel、Radial、Tibia
5.GYN：uterus、cervix、corpus uteri/cervix uterus、left ovarian vein、right ovarian vein、dominant follicle
6.Urology: prostate、residual urine、left kidney、right kidney、left suprarenal vein、right suprarenal、left testis、right testis、left seminal vesicle、right seminal vesicle
7.Abdomen：liver、CHD、partal vein diameter、CBD、pancreas、spleen、Internal diameter of abdominal aorta、kidney
8.Small parts：Thyroid
9.Software package：Measurement package、Software package、Medical records management software package

Probes：

1.Convex probe
Fundamental Frequency：2.0MHz/2.3MHz/2.5MHz/3.0MHz/3.5MHz/4.0MHz/4.6MHz/5.0MHz/5.4MHz,
Harmonic Frequency：4.0MHz/4.6MHz/5.0MHz，
2.Linear probe
Fundamental Frequency：4.0MHz/4.6MHz/5.0MHz/6.0MHz/7.0MHz/8.0MHz/9.2MHz/10.0MHz/12.0MHz/13.3MHz，
Harmonic Frequency：8.0MHz/9.2MHz/10.0MHz,
3.Trans-vaginal probe
Fundamental Frequency：3.0MHz/3.5MHz/4.0MHz/5.0MHz/5.4MHz/6.0MHz/7.0MHz/8.0MHz/10.0MHz，
Harmonic Frequency：6.0MHz/7.0MHz/8.0MHz，
4.Micro-convex probe
Fundamental Frequency：3.0MHz/3.5MHz/4.0MHz/5.0MHz/5.4MHz/6.0MHz/7.0MHz/8.0MHz，
Harmonic Frequency：6.0MHz/7.0MHz/8.0MHz，
5.Cardiac probe
Fundamental Frequency：1.7MHz/1.9MHz/2.1MHz/2.5MHz/3.0MHz/3.4MHz/3.8MHz/4.2MHz/5.0MHz，
Harmonic Frequency：3.4MHz/3.8MHz/4.2MHz，
6.4D Volume probe
Fundamental Frequency：2.0MHz/2.5MHz/3.0MHz/3.3MHz/3.7MHz/4.0MHz/5.0MHz/6.0MHz，
Harmonic Frequency：4.0MHz/5.0MHz/6.0MHz，
